0545 тип система 13 110-030 NASS катушки клапана соленоида
Напряжение тока:
AC220V AC110V/DC12V DC24V (±10%)
Размер отверстия:
14,6 mm
ТЕМПЕРАТУРА ОКРУЖАЮЩЕЙ СРЕДЫ:
- °C 20 | + °C 50
Применение:
Клапан соленоида воды и электронный дренажный клапан
Класс изоляции:
Ф, Х
Тип соединения:
ДИН43650А
Степень защиты с соединителем:
IP 65 (IP 67 по запросу)
Выделить:
113-030-0142 0545 катушка
,
113-030-0141 0545 катушка
,
тип магнит 230VAC Nass
230V AC 113-030-0142 113-030-0141 113-030-0138 Auto Drain Valve 0545 Coil
Everyone knows that solenoid valves play an important role in industrial applications, and they have a long running time, and sometimes there are some problems that make the equipment not function properly. Most of this problem is caused by improper use of the solenoid valve coil.
The solenoid valve coil may not be very secure at the time of installation. During the operation of the device, the coil is in a strong operation, so that the coil will fall, the solenoid valve will not operate normally, or some may fall, and some may not. It may cause the device to work for a while and not work properly, both of which will delay the work. At this time, the operation is relatively simple, and the coil can be firmly fixed on the solenoid valve. There is also a case where the solenoid valve coil may be burnt out due to excessive voltage, and the device may not operate normally.
Technical parameter of 0545 110-030 NASS Type Solenoid Valve Coil:
Code No
Voltages
Frequency(Hz)
Power (W)
Power (VA)
113-030-0123
24vDC
4,1
113-030-0144
24VAC
50
8,8
113-030-0144
24VAC
60
7,6
113-030-0128
220VAC
50
9,0
113-030-0128
240VAC
60
9,2
113-030-0142
230VAC
50
8,8
113-030-0142
230VAC
60
7,6
113-030-0121
220VAC
50
14,0
113-030-0124
24VDC
-
7,9
113-030-0135
24VAC
50
14,0
113-030-0135
24VAC
60
12,0
113-030-0279
110 VAC
50
13,9
113-030-0279
110VAC
60
12,2
113-030-0125
24VDC
-
11,9
113-030-0129
24VAC
50
21,0
113-030-0129
24VAC
60
18,0
113-030-0126
110VAC
50
21,5
113-030-0141
230 VAC
50
22,0
113-030-0141
230VAC
60
19,0
113-030-0120
12VDC
-
17,5
113-030-0127
24VAC
50
25,0
113-030-0132
24VDC
-
18,5
113-030-0120
36VAC
50
25,0
113-030-0137
110VAC
50
27,5
113-030-0140
110VAC
60
26,5
113-030-0137
120VAC
60
28,0
113-030-0133
220VAC
50
25,5
113-030-0122
220VAC
50
22,0
113-030-0138
230VAC
50
25,5
113-030-0133
240VAC
60
25,0
113-030-0138
240VAC
60
27,0
Main dimension of Nass Type 0545 Electronic Drain Solenoid Coils:
Phyical map of 113-030-0028 nass type electromagnetic coil:
Applicatoin of nass type 113-030-0035 electric magnetic coil:
More details about 0545 110-030 series Solenoid Coil can be found below the Youtube Video:
Product Features:
1. Using high quality wire which has UL approved; 2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.
